Self-priming diesel fire pump

Medium pressure portable centrifugal fire engine

Diesel motor

performances

  • Diesel thermal engine
  • Max flow 450 L / min
  • 300 l / min at 4 bar
  • 100 l / min at 7.5 bar

Further information

Weight 101 kg.
Length 73,5x61x62 cm
Engines


Information

reference:

VET 27-9 D

Categories: , Application job:

PUMP

Pump Type: Self-priming
Ø of Suction Connection: 50 mm
Delivery: 25/25/40 mm
Maximum flow: 450 L / min (27 m3 / h)
Total Manometric Height: 90 m
Maximum Suction Height: 6-7m
Grain size (Ø strainer hole): clear water
Mechanical seal: Ceramic carboy

ENGINE

Engine type: YANMAR
Fuel: Diesel
Tank capacity: 5,4 liters
Autonomy: 4:00 p.m.
Electric start + Self-returning launcher.
with integrated emergency rope pulley

MISCELLANEOUS FEATURES

Dimensions LxWxH: 735 x 610 x 620 mm
Net dry weight: 101 kg
Gross Weight packed: 104 kg

A selection of pumps adapted to your specific needs

Fire safety

Large range of firefighting and flood fighting motor pumps. Pumps can be skid-mounted, portable, or trailer-mounted

Marine - Sea water

Range of motor pumps resistant to sea water. Can be used for security services on ships and oil ports, commercial ports

Industrial building

Fire pumps are usually approved by a certification body and are powered by an electric or diesel engine or sometimes by a steam turbine.

Flood Construction site

Pumps used for lifting wastewater, evacuating loaded and muddy water, drying or irrigating.

Civil security

Motor pumps used during flooding to collect or drain water

Home Security

Motor pumps and a swimming pool to fight fires, as well as our range of cellar pumps intended for the evacuation of rainwater and clear water!
