Self-priming diesel fire pump
Medium pressure portable centrifugal fire engine
Diesel motor
performances
- Diesel thermal engine
- Max flow 450 L / min
- 300 l / min at 4 bar
- 100 l / min at 7.5 bar
Further information
| Weight | 101 kg |
|---|---|
| Length | 73,5x61x62 cm |
| Engines |
PUMP
Pump Type: Self-priming
Ø of Suction Connection: 50 mm
Delivery: 25/25/40 mm
Maximum flow: 450 L / min (27 m3 / h)
Total Manometric Height: 90 m
Maximum Suction Height: 6-7m
Grain size (Ø strainer hole): clear water
Mechanical seal: Ceramic carboy
ENGINE
Engine type: YANMAR
Fuel: Diesel
Tank capacity: 5,4 liters
Autonomy: 4:00 p.m.
Electric start + Self-returning launcher.
with integrated emergency rope pulley
MISCELLANEOUS FEATURES
Dimensions LxWxH: 735 x 610 x 620 mm
Net dry weight: 101 kg
Gross Weight packed: 104 kg
